Black painted telescopic fork suitable for Piaggio Bravo mopeds / mopeds.
Total fork length: 680 mm
Head tube length: 195 mm
Head tube thread: M27.5x1 (usually often referred to as M28x1)
Ø inner head tube (for stem mounting): 21.6 mm
The matching attachments, such as headset set etc., can be found under accessories.
Branded product from the Italian manufacturer EBR.
Details
| Total length | 675 mm, 610 mm |
| Manufacturer | EWC |
| Color | black, Chrome |
| Thread type | MF27.5x1 (fine pitch thread) |
| Adjustable | No |
| Spar end distance (center-center) | 140 mm |
| Surface | varnished, chrome-plated |
| Ø outer head tube | 27.6 mm |
| Ø spars | 28 mm |
| Ø head tube inside | 21.95 mm |
| Head tube length | 195 mm |
| Thread length | 55 mm |
| Fork bridge - center wheel axle | 390 mm |
| Distance brake cam to wheel axle center-center | 60 mm |
Suitable for the following models
| Piaggio | Bravo/Superbravo |
