Inlet gasket 1.6 mm | Puch X30 Velux / Sachs

BERU spark plug connector / 1 kΩ interference suppressed

Manufacturer: BERU · Material: Sheet metal (steel) · Color: silver · Spark plug socket: M4 · Cable available: No · Suppressed: Yes · Resistance: 1000 Ω · Ø cable: 5 mm · Ø cable: 7 mm · Pony spare part no.: A2099 · Sachs spare part no.: 0265 100 00

GPO flywheel trigger M26x1.5 / M22x1.5 | Puch, Sachs, Beta 521

Width across flats (trigger): 27 mm · Width across flats Screw: 19 mm · Manufacturer: GPO · Clamping depth: 10 mm · Material: Steel · Surface: blackened · Number of components: 1 pcs · Total length: 55 mm · Total length: 75 mm · Thread type: MF22x1.5 (fine pitch thread) · Thread type: MF26x1.5 (fine pitch thread) · Strength class: 8.8 · Area of application: (Dis)assembly tool

Exhaust gasket original | Puch

Material: Sealing carton · Place of use: Outlet · Thickness: 1.8 mm · Ø inside: 18 mm · Ø inside: 22 mm · Number of fixing points: 2 pcs · Hole spacing: 42.5 mm · Ø mounting hole: 6.3 mm

Motorex engine oil (gear oil) manual 450 ml

Temperature resistance (min.): -30 - 220 °C · Manufacturer: Motorex · Oil type: GL4 · Viscosity (SAE): 80W · Area of application: Gearbox lubrication with clutch · Contents [ml]: 450 ml · Gearbox type: Foot control · Gearbox type: Manual gearshift

Meteor piston 38 mm | Sachs 50/2, 503 (A2772)

Nominal diameter: 38 mm · Manufacturer: Meteor · Ø outside piston (A): 37.95 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Thick piston ring: 1.6 mm · Ø piston pin (B): 12 mm · Weight: 79 g · Pony spare part no.: A2772 · Pony spare part no.: A4358 · Sachs spare part no.: 0286 377 010 · Sachs spare part no.: 0286 378 005

Clutch cable / brake cable Ø 1.5 mm x 225 cm (pear-shaped nipple)

Ø Stranded wire: 1.5 mm · Cable length: 2250 mm · Nipple shape: Pears · Ø nipple: 3.5 mm · Ø nipple: 6 mm · Nipple length: 10 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Surface: blue galvanized · Number of components: 1 pcs · Piaggio spare part no.: 270460

Inlet gasket 3.2 mm | Puch X30 Velux / Sachs

Place of use: Admission · Thickness: 3.2 mm · Hole spacing inlet: 32 mm

swiing® revival stud bolt inlet M5x26 mm galvanized (strength 10.9) | Sachs (A1474)

Manufacturer: swiing® revival parts · Material: Steel · Surface: blue galvanized · Thread type: M5x0.8 (standard thread) · Total length: 26 mm · Strength class: 10.9 · Thread length: 7 mm · Thread length: 14 mm · Pony spare part no.: A1474 · Sachs spare part no.: 0241 031 101

swiing® revival stud bolt set M6x30 (strength 10.9) galvanized

Manufacturer: swiing® revival parts · Material: Steel · Surface: blue galvanized · Diameter: 6 mm · Thread type: M6x1 (standard thread) · Drive: External hexagon · Width across flats SW: 10 mm · Strength class: 8 · Strength class: 10.9 · Total length: 30 mm · Thread length: 12 mm

Intermediate flange diaphragm 12 mm | Sachs 502, 50/2, 50/3, 50/4 (A2621)

Material: Aluminum · Area of application: Standard · Number of flaps: 2 pcs · Thread type: M5x0.8 (standard thread) · Ø inside: 12 mm · Number of fixing points: 4 pcs · Mounting type: Screws · Hole spacing: 31 mm · Hole spacing: 67 mm · Pony spare part no.: A2621 · Sachs spare part no.: 0286 210 001
