NTN 6202 ball bearing 15/35/11 | Belmondo crankshaft

swiing® ingenious bearing press-on plunger Ø 35 mm

Ø inside: 15 mm · Ø outside: 35 mm · Manufacturer: swiing® ingenious parts · Number of components: 2 pcs · Material: Aluminum · Material: Steel · Area of application: Special tool · Surface: anodized · Ø Pin: 15 mm · Total length: 52.5 mm

KMC Standard pedal chain

Manufacturer: KMC · Material: Steel · Surface: blank / oiled · Number of chain links: 112 pcs · Chain type: 410 · Rolling circumference: 1422 mm · Color: gray · Chain pitch: 1/2" x 1/8" · Chain lock type: Spring lock

swiing® ingenious needle roller bearing 12/15/16.2 "Racing" silver cage

Ø inside: 12 mm · Bearing cage: Silver cage · Ø outside: 15 mm · Manufacturer: swiing® ingenious parts · Bearing type: Needle roller and cage assembly · Dimension needle bearing: 12/15 x 16.2 · Width: 16.2 mm · Tomos OEM number: 035548

Union pedals plastic standard

Drive: Hexagon socket · Drive: Outer edge · Width across flats SW: 15 mm · Manufacturer: Union · Material: Plastic · Material: Steel · Surface: rubberized · Color: black · Reflectors: Yes · Thread type: FG14.3 (9/16" 20G) · Total length: 129 mm · Width: 77 mm · Height: 29 mm

Motorex 2-stroke mixed oil semi-synthetic 1 L (for running in cylinders!)

Manufacturer: Motorex · Oil type: semi-synthetic · Contents [ml]: 1000 ml · Area of application: Standard · Color: green

swiing® revival Ø 9 mm wedge 3.5° pedal crank galvanized

Ø outside: 9 mm · Total length: 43 mm · Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Color: silver · Angle crank wedge: 3.5° · Thread type: M7x1 (standard thread)

Piston 38.945 mm #A | Zündapp Belmondo Type 247

Ø outside piston (A): 38.945 mm · Ø piston pin (B): 12 mm · Compression height (C): 26.3 mm · Curvature (D): 1.3 mm · Total piston height (E): 51.65 mm · Number of piston rings (F): 1 pcs · Nominal diameter: 39 mm · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Tolerance group: A · Piston weight: 84 g

NSK 16005 Ball bearing 25/47/8 Gearbox | Zündapp Belmondo (Type 247)

Ø inside: 25 mm · Bearing cage: "-" Sheet steel cage ball-guided · Ø outside: 47 mm · Stock number: 16005 · Inner ring width: 8 mm · Manufacturer: NSK · Bearing clearance: CM (special/noise-reduced) · Material: Steel · Area of application: Standard · Bearing type: Deep groove ball bearing · Surface: blank · Ball bearing closed: No · Width: 8 mm

Oil seal NBR 15/24/7 BS | Zündapp (Type 247)

Simmering type: BS - With sheet metal outer casing / one sealing lip / one dust lip. · Ø inside: 15 mm · Ø outside: 24 mm · Manufacturer: Zündapp · Material: NBR · Temperature resistance (min.): -30 - 100 °C · Width: 7 mm

GPO exhaust clamp 28 mm chrome

Ø inside: 28 - 30 mm · Ø outside: 34 mm · Manufacturer: GPO · Material: Steel · Surface: chrome-plated · Color: Chrome · Mounting type: Nuts & bolts · Material thickness: 2.7 mm · Total length: 19 mm · Width: 57 mm

NTN 6202 Ball bearing 15/35/11

Ø inside: 15 mm · Bearing cage: "-" Sheet steel cage ball-guided · Ø outside: 35 mm · Stock number: 6202 · Inner ring width: 11 mm · Manufacturer: NTN · Bearing clearance: CM (special/noise-reduced) · Groove ring: No · Material: Steel · Bearing type: Deep groove ball bearing · Surface: blank · Ball bearing closed: No · Width: 11 mm
