Operating instructions | Maxi / Maxi 2A

GPO oil filler plug black | Puch Z50, ZA50

Total length: 25 mm · Manufacturer: GPO · Ø outside: 16.4 mm · Material: NBR · Area of application: Standard · Color: black · Surface: raw · Clamping diameter: 13 mm · Ø mounting hole: 11 mm · Puch spare part no.: 364.2.10.660.1

GPO license plate holder Inox

Manufacturer: GPO · Material: Chrome steel (stainless steel) · Total length: 145 mm · Width: 105 mm · Ø mounting hole: 5 mm · Height: 5.3 mm · Number of fixing points: 2 pcs · Color: silver · Hole spacing: 30 mm · Hole spacing: 50 mm · Mounting type: Nuts & bolts · Thread length: 8 mm · Thread type: M5x0.8 (standard thread)

Magura cable clamp Ø 8 x 15 mm

Ø outside: 8 mm · Total length: 15 mm · Drive: External hexagon · Drive: Slot · Screw head: Hexagon · Width across flats SW: 7 mm · Thread type: M6x1 (standard thread) · Manufacturer: Magura · Thread length: 7 mm · Ø Cable bushing: 2.3 mm · Ø Bundle: 6 mm · Material: Brass · Material: Steel · Surface: blue galvanized · Surface: nickel-plated · Area of application: Standard

Clutch 3-jaw (aluminum) | Puch E50

Area of application: Original · Area of application: Standard · Material: Aluminum · Material: Steel · Material addition: Composite materials · Recording type: Cone mounting · Ø inside: 12 mm · Ø inside: 14.6 mm · Ø outside: 93 mm · Number of jaws: 3 pcs · Number of springs: 3 pcs · Thickness: 20.9 mm

Black bench seat

Manufacturer: Made in Portugal · Ø Saddle tube holder: 22 mm · Material: Imitation leather · Spring-loaded: No · Total length: 300 mm · Lettering: No · Width: 215 mm · Height: 80 mm · Height: 115 mm · Number of fixing points: 1 pcs · Color: black

swiing® revival stud bolt inlet/outlet M6 x 30 mm (10.9 strength)

Manufacturer: swiing® revival parts · Material: Steel · Surface: blue galvanized · Total length: 30 mm · Diameter: 5.95 mm · Strength class: 10.9 · Thread length: 12 mm · Thread type: M6x1 (standard thread)

swiing® revival gearbox cover gasket | Puch Maxi S LG2 ZA50 engine

Manufacturer: swiing® revival parts · Thickness: 0.3 mm · Total length: 175 mm · Material: Sealing paper · Width: 133 mm · Number of components: 1 pcs · Color: sand-colored · Number of fixing points: 6 pcs

Spare parts catalog | Puch Maxi S, N, S-2A (CH)

Material: Paper · DIN format: A4 · Number of pages: 116 pcs

Repair instructions | Puch Maxi 1-speed automatic

Material: Paper · DIN format: A4 · Number of pages: 21 pcs

Outlet gasket 18 - 22 mm metal ring

Place of use: Outlet · Material: Sealing carton · Material: Sheet metal (steel) · Ø inside: 22 mm · Ø mounting hole: 6.7 mm · Thickness: 2 mm · Number of fixing points: 2 pcs · Hole spacing: 38 - 42.5 mm
