Service book | Puch models '87

swiing® revival cable guide mudguard black | Puch

Manufacturer: swiing® revival parts · Material: Plastic · Color: black · Mounting type: Plug connection · Number of fixing points: 2 pcs · Hole spacing: 63 mm · Total length: 74 mm · Height: 12.5 mm

Main stand black (budget) | Puch Maxi S, P1 / X30 NS, NL, NG

Total height: 220 mm · Material: Steel · Surface: varnished · Stand base - center mount (A): 207 mm · Color: black · Total width of stand base (B): 217 mm · Wide receptacle (C): 66 mm · Ø Receptacle (D): 18 mm · Spring nipple distance - center pivot axis (E): 75 mm · Wide upright foot (F): 20 mm · Wide upright foot (F): 50 mm

GPO rubber for swing arm mounting

Ø inside: 24 mm · Ø outside: 32 mm · Ø outside: 37 mm · Manufacturer: GPO · Material: Rubber · Area of application: Standard · Surface: raw · Color: black · Total length: 90 mm

Exhaust 18 mm original 1-piece | Puch Maxi S, N

Manufacturer: Puch · Material: Steel · Surface: chrome-plated · Color: Chrome · Mounting type: Welded lug · Number of fixing points: 4 pcs · Ø Flame tube outside: 18 mm · Flame tube attachment: Flange

swiing® revival rubber stand stop black | Puch

Ø outside: 22.3 mm · Waistband height: 3 mm · Manufacturer: swiing® revival parts · Ø Bundle: 14.9 mm · Material: Rubber · Area of application: Standard · Color: black · Ø mounting hole: 12.5 mm · Total length: 15.5 mm

Nut M12x1 x 10 SW19 Wheel nut galvanized

Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Nut type: Hexagon nut · Thread type: MF26x1 (fine pitch thread) · Drive: External hexagon · Height: 10 mm · Thread depth: 10 mm · Width across flats SW: 19 mm · Strength class: 8

GPO wheel clamp 12 mm cranked solid (per piece)

Ø inside: 12.1 mm · Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Ø outside: 23 mm · Cranking (offset): 6 mm · Thread type: M6x1 (standard thread) · Total length: 78 mm · Thread length: 36 mm

IMCA shock absorber 30 cm black

Ø outside: 45 mm · Manufacturer: IMCA · Material: Steel · Damping type: Spring · Adjustable: Yes · Surface: varnished · Color: black · Ø spars: 28 mm · Mounting type: Nuts & bolts · Number of fixing points: 2 pcs · Ø Fastening inside: 10 mm · Total length: 300 mm

Spare parts catalog | Puch Maxi S, N, S-2A (CH)

Material: Paper · DIN format: A4 · Number of pages: 116 pcs

Meteor piston 38 mm #C | Sachs 503 AB/AC

Manufacturer: Meteor · Ø outside piston (A): 37.98 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 51 mm · Number of piston rings (F): 1 pcs · Nominal diameter: 38 mm · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: C · Piston weight: 75 g · Pony OEM number: A5685C · Sachs OEM number: 0286 382 306
