Tuning set with approx. 65 cc displacement for your Piaggio Si, Bravo 2, Superbravo and Grillo moped / moped.
The individual components of the tuning set are of high quality and guarantee optimum power delivery. In addition, the selected components are relatively unobtrusive and quiet. You can also fine-tune your engine with the included düsenset.
The tuning set consists of the following parts:
- Cylinder: Malossi Ø 43 mm, axe 10 / 12 mm
- Cylinder head: Malossi 41 - 43 mm
- Carburettor: Dell'Orto 13/13 SHA
- Air filter: Malossi air filter
- Exhaust: 25 mm Sito Plus
- Petrol plug: B8HS (long thread)
- Düse: Düsenset 50 - 70
Please select the appropriate cylinder depending on whether you have a connecting rod with 10 or 12 mm piston pin.
Other parts such as racing crankshafts or a bearing set can be found in the accessories section.
Buy this complete set and you will receive a substantial discount on the retail price of the individual parts.
Quality product from the Italian manufacturer Malossi.
The set includes the following fixed parts:
Nozzle size: 66 · Manufacturer: Dell'Orto · Camouflaged: No · Material: Aluminum · Color: black · Carburetor type: SHA (type 3) · Nominal diameter: 13 mm · Ø Internal connection: 16 mm · Ø without reducing sleeve: 18 mm · Ø Inside entrance: 13 mm · Ø Output inside: 13 mm · Ø Air filter connection: 50.8 mm · Ø fuel hose connection: 6 mm, 5.2 mm · Choke control: Hand choke · Nozzle thread: M5x0.8 (standard thread) · Mounting type: Plug connection clamped · Total length: 55 mm · Width: 60 mm · Height: 118 mm · Area of application: Tuning
Manufacturer: SITO · Material: Steel · Surface: varnished · Color: black · Ø outside: 14 mm · Total length: 720 mm · Ø Silencer: 70 mm · Ø Flame tube outside: 25 mm · Ø Internal connection: 22.3 mm · Exhaust type: Cylindrical · Mounting type: Welded lug · Number of fixing points: 1 pcs · Flame tube attachment: Plug connection clamped
Manufacturer: Malossi · Camouflaged: No · Color: black · Material: Plastic · Filter type: Foam · Total length: 31.2 mm · Width: 95 mm · Height: 88.7 mm · Ø Internal connection: 51 mm · Ø outside: 53.2 mm · Mounting type: Plug connection clamped · Area of application: Tuning
Nozzle size: 50, 52, 55, 58, 60, 62, 64, 66, 68, 70 · Manufacturer: swiing · Material: Brass · Quantity: 10 pcs · Carburetor type: SHA (type 3), SHA (type 4), PHBG · Nozzle type: Main nozzle · Nozzle thread: M5x0.8 (standard thread) · Total length: 8 mm · Drive: Slot
Hole pattern [mm]: 35 x 55 · Manufacturer: Malossi · Material: Aluminum · Ø cylinder: 41 - 43 mm · Camouflaged: No · Number of fixing points: 3 pcs · Candle thread: short · Decompressor: Yes · Total length: 134 mm · Width: 94 mm · Height: 52 mm · Area of application: Racing
Details
| Manufacturer | Malossi, Dell'Orto, SITO, swiing, NGK |
| Area of application | Tuning |
| Displacement | 65 ccm |
| Nominal diameter | 44 mm |
| Crankshaft stroke | 43 mm |
| Ø piston pin (B) | 10 mm, 12 mm |
| Outlet type | clamped |
| Decompressor | Yes |
| Camouflaged | No |
Suitable for the following models
| Piaggio | Si Bravo/Superbravo Grillo Super Bravo |
