Two pieces of silent block with spacer tube for engine mounting for your moped / moped with Sachs 503 engines (2BL / ABL / AB). The mounting rubbers also fit Sachs 504 & 505 engines (manual and automatic), as well as Alpa Mini / Enduro, KTM GP40 with Sachs 535 engine.
Ø outer: 21.7 mm
Ø collar: 28 mm
Length: 23 mm
Dimension spacer tube: Ø12/8.4 x 48 mm
Scope of delivery: 2x silent rubber, 1x spacer tube
You can find more attachments and alternative silentblocs in the accessories section.
Original spare part number: A4286 & A4271
A quality product made in Germany.
Details
Material | Rubber, Steel |
Surface | blue galvanized |
Color | black, silver |
Ø Bundle | 28 mm |
Manufacturer | Made in Germany |
Ø outside | 21.7 mm |
Total length | 48 mm |
Width | 23 mm |
Ø inside | 8.4 mm |
Pony spare part no. | A4286, A4271 |
Suitable for the following models
Sachs | 503 - ABL, 2AL / 2BL, AB 504 (ohne Tretwelle) 505 (mit Tretwelle) - 1A (AT), 2 A (HG) 535 |
