swiing® ingenious 0.5 mm lifting plate aluminum original | Puch

Large outlet seal with metal ring

Material: Sealing carton · Material: Sheet metal (steel) · Place of use: Outlet · Thickness: 2.1 mm · Reinforced: Yes · Ø outlet inside: 27 mm · Hole spacing outlet: 42.5 mm · Ø screw holder: 6.3 mm · Area of application: Tuning

GPO gasket cylinder base 0.35 mm original | Puch

Manufacturer: GPO · Material: Oiled paper · Place of use: Cylinder base · Nominal diameter: 47 mm · Thickness: 0.3 mm · Ø inside: 47 mm · Hole pattern [mm]: 44 x 44 · Area of application: Standard · Puch OEM number: 349.3.10.013.1

Elring Curil T2 sealing compound 70 ml green (polyurethane) non-hardening

Manufacturer: Elring · Area of application: Chemistry · Color: green · Contents [ml]: 70 ml · Gap dimension (max.): 0.2 mm · Temperature resistance (min.): -55 - 250 °C

MBR retaining plate oil seal on ignition side "Racing" Inox

Manufacturer: MBR · Material: Chrome steel (known as Nirosta®) · Surface: brushed · Color: silver · Ø inside: 25.3 mm · Ø outside: 89.4 mm · Number of fixing points: 4 pcs · Area of application: Tuning

swiing® ingenious 0.5 mm lift plate aluminum tuning | Puch

Manufacturer: swiing® ingenious parts · Material: Aluminum · Surface: anodized · Place of use: Cylinder base · Thickness: 0.5 mm · Ø cylinder: 45 mm · Area of application: Racing

GPO 38 mm gasket cylinder head 0.2 mm | Puch

Place of use: Cylinder head · Thickness: 0.2 mm · Manufacturer: GPO · Material: Aluminum · Area of application: Original · Area of application: Standard · Ø cylinder: 38 mm · Ø screw holder: 7 mm · Alternative version of the Puch OEM number: 349.1.10.004.1

swiing® ingenious crankshaft High End (+1 mm stroke) (Version 2.0) | Puch E50

Manufacturer: swiing® ingenious parts · Weight: 970 g · Material: Aluminum · Area of application: High End · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 44 mm · Ø piston pin (B): 12 mm · Thread type: MF10x1 (fine pitch thread) · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 66 mm · Thread length: 11 mm · Thread length: 15 mm · Ø crank webs: 69.9 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Length 3rd paragraph: 25 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Number of gears: 1 pcs

swiing® ingenious crankshaft High End C3/4 & FPM (+1 mm stroke) (Version 2.0) | Puch E50

Manufacturer: swiing® ingenious parts · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 44 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Thread type: MF10x1 (fine pitch thread) · Total length crankpin ignition side: 66 mm · Ø crank webs: 69.9 mm · Ø Connecting rod eye: 15 mm · Ø piston pin (B): 12 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Thread length: 11 mm · Thread length: 15 mm · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Area of application: High End · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Weight: 970 g · Number of gears: 1 pcs

GPO cylinder stud bolt set special M6x106 mm galvanized | Puch

Manufacturer: GPO · Diameter: 7 mm · Material: Steel · Surface: galvanized (blue) · Total length: 106 mm · Thread type: M6x1 (standard thread) · Drive: External hexagon · Width across flats SW: 10 mm · Thread length: 15 mm · Thread length: 19 mm · Strength class: 10 · Strength class: 10.9 · Alternative version of the Puch OEM number: 360.1.10.034.1

Rito crankshaft Racing (+1mm stroke) (old model) | Puch E50

Dimension needle bearing: 12 / 15 x 15 mm (axe 12) · Manufacturer: Rito · Material: Aluminum · Material: Steel · Cheek type: Full cheeks · Crankshaft stroke: 44 mm · Thread length: 10.5 mm · Thread length: 12.5 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 67 mm · Ø crank webs: 69.9 mm · Area of application: High End · Thread type: MF10x1 (fine pitch thread) · Ø Connecting rod eye: 16 mm · Ø piston pin (B): 12 mm · Ø Bearing seat (clutch side): 17 mm · Weight: 939 g · Ø Bearing seat (ignition side): 17 mm · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Length 2nd paragraph: 14.5 mm · Length 3rd paragraph: 25 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.3 mm · Number of gears: 1 pcs · Puch OEM number: 349.1.10.015.0 · Alternative version of the Puch OEM number: 349.1.10.015.0
