Sachs engine & gearbox

Airsal piston pin lock Ø 12 mm (single)

Manufacturer: Airsal · Material: Spring steel · Surface: blank · Number of sensors / lugs: 1 pcs · Ø outside: 12 mm

Sachs engine plate

Width: 58 mm · Height: 15 mm · Shape: rectangular · Number of fixing points: 2 pcs

M8 sealing ring Fiber

Thickness: 1 mm · Material: Fiber · Surface: raw · Ø inside: 8.3 mm · Ø outside: 13.7 mm · Place of use: Carburetor · Place of use: Motor housing · Area of application: Standard · Puch OEM number: 26482

Meteor piston 38 mm #A | Sachs 503 AB/AC

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 37.96 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 51 mm · Number of piston rings (F): 1 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Tolerance group: A · Pony OEM number: A5685A

Meteor piston 38.3 mm oversize | Sachs 50/2 & 503

Manufacturer: Meteor · Nominal diameter: 38 mm · Ø outside piston (A): 38.25 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3 mm · Total piston height (E): 53 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Flank safety device (FS) · Piston ring height: 2 mm · Piston weight: 81 g · Pony OEM number: A2773 · Sachs OEM number: 0286 377 011

swiing® revival membrane seal 0.4 mm | Sachs 50/2, 50/3, 50/4 (A1840)

Manufacturer: swiing® revival parts · Material: Oiled paper · Thickness: 0.4 mm · Hole spacing inlet: 67 mm · Pony OEM number: A1840 · Sachs OEM number: 0250 106 00

GPO piston pin extractor Ø 10, 12, 14 mm

Manufacturer: GPO · Material: Steel · Surface: burnished · Number of components: 7 pcs · Diameter: 10 mm · Diameter: 12 mm · Diameter: 14 mm · Total length: 130 mm · Width across flats SW: 10 mm · Width across flats SW: 17 mm · Area of application: (Dis)assembly tool

Inlet seal 17 mm spigot (5.5 mm) | Sachs 50/3

Place of use: Admission · Thickness: 5.5 mm · Hole spacing inlet: 30 mm

swiing® revival puller clutch basket manual | Sachs

Material: Steel · Surface: blackened · Surface: galvanized (blue) · Manufacturer: swiing® revival parts · Number of components: 4 pcs · Total length: 106 mm · Thickness: 25 mm · Width across flats Screw: 19 mm · Thread type: MF12x1.25 (fine pitch thread) · Area of application: (Dis)assembly tool

Housing cover small Occ. | Sachs 50/2 (Type 2)

Manufacturer: Sachs · Material: Aluminum · Surface: varnished · Color: silver · Pony OEM number: A1024 · Sachs OEM number: 0211 069 206

swiing® revival clamp body reinforced | Sachs 503 AB, AC, ADV, ABL (A1196)

Manufacturer: swiing® revival parts · Surface: Hardened · Ø inside: 19 mm · Ø outside: 26.8 mm · Material: Steel · Number of teeth: 24 pcs · Height: 10.9 mm · Pony OEM number: A1196 · Sachs OEM number: 0232 186 100

Spacer washer 16/22/0.1 pinion shaft / pedal shaft | Sachs

Nominal diameter inside: 16 mm · Manufacturer: Sachs · Surface: blank / oiled · Material: Steel · Thickness: 0.1 mm · Ø inside: 16 mm · Ø outside: 22 mm

Protective cap shift/clutch lever | Sachs 50/2, 503 2AL/2BL (A1687)

Material: Steel · Surface: galvanized (blue) · Ø inside: 14.15 mm · Ø outside: 20 mm · Height: 2.4 mm · Pony OEM number: A1687 · Sachs OEM number: 0246 012 000

Slotted nut M5 shift rod | Sachs 50/3

Material: Steel · Surface: burnished · Nut type: Slotted nut · Thread type: M5x0.8 (standard thread) · Drive: Slot

Fan wheel | Sachs 50/2

Material: Plastic · Number of fixing points: 3 pcs · Alternative version of the Pony OEM number: A1026 · Alternative version of the Sachs OEM number: 0211 070 105

Spacer washer 15.7/21/1 pinion shaft | Sachs

Nominal diameter inside: 16 mm · Manufacturer: Sachs · Surface: blank / oiled · Material: Steel · Thickness: 1 mm · Ø inside: 16 mm · Ø outside: 22 mm · Pony OEM number: A1577 · Sachs OEM number: 0244 081 066

Athena 38 mm cylinder kit without mounting parts | Sachs (504), 505, 508

Manufacturer: Athena · Material: Aluminum · Camouflaged: No · Surface: sandblasted · Area of application: Tuning · Crankshaft stroke: 44 mm · Displacement: 50 ccm · Nominal diameter: 38 mm · Hole spacing inlet: 32 mm · Ø cylinder neck: 51.7 mm · Ø outlet inside: 28.3 mm · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Inlet window: 23.6 x 12.8 / 16.5 · Hole spacing outlet: 50 mm · Thread inlet: M6x1 (standard thread) · Decompressor: M10x1.5 · Hole pattern [mm]: 56/61 x 56 · Outlet type: straight · Thread outlet: M8x1.25 (standard thread)

Jasil crankshaft full cheeks | Sachs 505, 535 A1, 535 AV

Manufacturer: Jasil · Cheek type: Full cheeks · Area of application: Standard · Crankshaft stroke: 44 mm · Thread type: MF10x1 (fine pitch thread) · Total length of crankpin on clutch side: 77.5 mm · Total length crankpin ignition side: 74 mm · Ø Bearing seat (clutch side): 14.95 mm · Ø Bearing seat (ignition side): 14.95 mm · Alternative version of the Sachs OEM number: A4477

Jasil crankshaft (axe 12 mm) | Sachs 50/5 & 50/6

Manufacturer: Jasil · Cheek type: Full cheeks · Area of application: Standard · Thread type: MF10x1 (fine pitch thread) · Thread type: MF12x1.25 (fine pitch thread) · Total length of crankpin on clutch side: 72 mm · Total length crankpin ignition side: 72 mm · Ø piston pin (B): 12 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Number of gears: 5 pcs · Number of gears: 6 pcs

Jasil crankshaft axe 14 mm | Sachs 506

Manufacturer: Jasil · Cheek type: Full cheeks · Area of application: Standard · Thread type: MF10x1 (fine pitch thread) · Thread type: MF12x1.5 (fine pitch thread) · Total length of crankpin on clutch side: 86 mm · Total length crankpin ignition side: 73 mm · Ø piston pin (B): 14 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Number of gears: 5 pcs · Number of gears: 6 pcs

Jasil crankshaft | Sachs 503 AC / ADV (A3337 / A2904)

Dimension needle bearing: 12 / 15 x 12.8 mm (axe 12) · Manufacturer: Jasil · Weight: 964 g · Material: Steel · Cheek type: standard · Area of application: Standard · Crankshaft stroke: 44 mm · Thread type: MF10x1 (fine pitch thread) · Connecting rod length center-center: 86 mm · Total length of crankpin on clutch side: 97 mm · Total length crankpin ignition side: 62 mm · Ø crank webs: 83 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Thread length: 7 mm · Thread length: 11 mm · Ø Bearing seat (clutch side): 12 mm · Ø Bearing seat (ignition side): 15 mm · Wide crank webs: 34.2 mm · Length 1st paragraph: 9.4 mm · Length 2nd paragraph: 19.4 mm · Length 3rd paragraph: 74 mm · Ø 1st step (on the coupling side): 17 mm · Ø 2nd shoulder (on the clutch side): 12 mm · Ø 3rd step (on the clutch side): 11.6 mm · Length of shoulder (ignition side): 32 mm · Number of gears: 2 pcs

Jasil crankshaft | Sachs 503 AB-CH / ABL CH (A2901 / A2902)

Manufacturer: Jasil · Weight: 875 g · Material: Steel · Cheek type: standard · Area of application: Standard · Crankshaft stroke: 42 mm · Thread type: MF10x1 (fine pitch thread) · Connecting rod length center-center: 84 mm · Total length crankpin ignition side: 101 mm · Ø crank webs: 85 mm · Ø piston pin (B): 12 mm · Ø Connecting rod eye: 15 mm · Thread length: 11 mm · Ø Bearing seat (clutch side): 15 mm · Ø Bearing seat (ignition side): 15 mm · Dimension needle bearing: 12 / 15 x 12.8 mm (axe 12) · Wide crank webs: 30.3 mm · Length 1st paragraph: 19 mm · Length 2nd paragraph: 51 mm · Ø 1st step (on the coupling side): 15 mm · Ø 2nd shoulder (on the clutch side): 14 mm · Length of shoulder (ignition side): 34 mm · Number of gears: 2 pcs · Alternative version of the Pony OEM number: A2900 · Pony OEM number: A2901 · Pony OEM number: A2902 · Alternative version of the Sachs OEM number: 0288 115 002 · Alternative version of the Sachs OEM number: 0288 115 102

M8 copper ring 8.3/11.8/0.8

Ø inside: 8.3 mm · Ø outside: 11.8 mm · Material: Copper · Thickness: 0.8 mm

M10 copper ring 10.4/13.8/0.8

Ø inside: 10.4 mm · Ø outside: 13.8 mm · Material: Copper · Thickness: 0.8 mm

swiing® revival manual shift spring | Sachs 50/2, 503 2AL, 2BL (A1337)

Spring design: Tension spring · Manufacturer: swiing® revival parts · Length spring hook: 8 mm · Ø wire: 1.25 mm · Color: gray · Material: Spring steel · Surface: burnished · Total length: 28 mm · Ø inside: 6 mm · Ø outside: 8.5 mm · Pony OEM number: A1337 · Sachs OEM number: 0239 102 100

GPO retaining plate clutch basket Sachs

Manufacturer: GPO · Material: Steel · Surface: galvanized (blue) · Total length: 135 mm · Width: 51 mm · Thickness: 4.6 mm · Ø inside: 40 mm · Number of components: 1 pcs · Area of application: Special tool

Gasket cylinder base Sachs 50/2 & 503 (1 mm)

Thickness: 1 mm · Material: Sealing carton · Place of use: Cylinder base · Hole pattern [mm]: 60 x 40 · Area of application: Standard · Alternative version of the Pony OEM number: A1848 · Alternative version of the Sachs OEM number: 0250 113 100

Copper ring exhaust gasket Sachs 503 AB, AC, ADV

Thickness: 3.4 mm · Material: Copper · Place of use: Outlet · Ø outside: 29.1 mm · Ø outlet inside: 23.1 mm

O-ring cylinder head gasket Sachs 503 AB, ADV, AC (A7678)

Thickness: 3.5 mm · Manufacturer: Sachs · Ø inside: 51.5 mm · Nominal diameter: 58 mm · Place of use: Cylinder head · Ø outside: 58.5 mm · Ø outlet inside: 53 mm

NewFren clutch plates | Sachs 50/2, 503 2AL/2BL (A3887)

Thickness: 3.3 mm · Manufacturer: NewFren · Material: Composite materials · Material: Steel · Ø inside: 30 mm · Ø inside: 36 mm · Recording type: Interlocking · Number of slats: 2 pcs · Ø outside: 93.8 mm · Area of application: Standard · Pony OEM number: A3887 · Sachs OEM number: 0659 010 006

GPO clutch plates 3.8 mm special | Sachs manual

Thickness: 3.8 mm · Manufacturer: GPO · Number of slats: 2 pcs · Area of application: Standard

swiing® revival inlet seal | Sachs 503 AB, ADV

Thickness: 1.1 mm · Manufacturer: swiing® revival parts · Place of use: Admission · Hole spacing inlet: 38 mm

NewFren clutch plate | Sachs 504 (A4292)

Manufacturer: NewFren · Number of slats: 1 pcs · Area of application: Standard

NewFren clutch plates (3 pcs.) | Sachs >50 ccm

Manufacturer: NewFren · Number of slats: 3 pcs · Area of application: Standard

Nut & spring washer clutch hub | Sachs

Nut type: Hexagon nut · Thread type: MF12x1 (fine pitch thread) · Drive: External hexagon · Width across flats SW: 17 mm

GPO outlet set large (gasket, stud bolts & nuts) | Sachs 503 AB, AC

Ø inside: 27 mm · Total length: 44 mm · Ø mounting hole: 8.5 mm · Width: 67 mm · Thickness: 2 mm · Hole spacing: 44 - 50 mm

swiing® revival bolt set cylinder head galvanized | Sachs 503 / 50/2 / 50/3 / 50/4

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Thread type: M6x1 (standard thread) · Total length: 34 mm · Drive: External hexagon · Color: silver · Screw head: Hexagon · Width across flats SW: 10 mm · Thread length: 22 mm · Shank: Yes · Ø shaft: 5.85 mm · Number of components: 12 pcs · Shank length: 8 mm · Strength class: 10.9 · Area of application: Standard

swiing® revival screw set cylinder head Inox | Sachs 503 / 50/2 / 50/3 / 50/4

Manufacturer: swiing® revival parts · Material: Chrome steel (stainless steel) · Thread type: M6x1 (standard thread) · Total length: 34 mm · Drive: External hexagon · Screw head: Hexagon · Width across flats SW: 10 mm · Thread length: 22 mm · Shank: Yes · Ø shaft: 5.85 mm · Number of components: 12 pcs · Shank length: 8 mm · Area of application: Standard

swiing® revival locking plate drive wheel Inox | Sachs 50/2, 50/3, 50/4, 503 2AL/2BL (A1717)

Manufacturer: swiing® revival parts · Material: Chrome steel (stainless steel) · Thickness: 0.5 mm · Number of lobes: 1 pcs · Pony OEM number: A1717 · Sachs OEM number: A1717 · Sachs OEM number: 0246 049 000

swiing® revival washer Ø 24 mm | Sachs 50/2, 50/3, 50/4, 503 AAL (A1602)

Manufacturer: swiing® revival parts · Color: Chrome · Ø outside: 24 mm · Thickness: 5 mm · Pony OEM number: A1602 · Sachs OEM number: A1602 · Sachs OEM number: 0244 114 000

Athena 48 mm cylinder kit without mounting parts | Sachs (504), 505, 508

Manufacturer: Athena · Camouflaged: No · Surface: sandblasted · Nominal diameter: 48 mm · Material: Aluminum · Crankshaft stroke: 44 mm · Ø piston pin (B): 12 mm · Ø cylinder neck: 51.6 mm · Number of fixing points: 4 pcs · Area of application: Tuning · Outlet type: clamped · Decompressor: M10x1.5

Athena 45 mm cylinder kit incl. mounting parts | Sachs (504), 505, 508

Manufacturer: Athena · Material: Aluminum · Surface: sandblasted · Nominal diameter: 45 mm · Crankshaft stroke: 44 mm · Ø piston pin (B): 12 mm · Ø cylinder neck: 51.7 mm · Ø Outlet outside: 25.9 mm · Ø outlet inside: 19.5 mm · Ø Inlet inside: 14.3 mm · Inlet window: 23.4 x 12.6 · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 31.5 mm · Hole spacing outlet: 50 mm · Outlet type: clamped · Outlet type: straight · Number of fixing points: 4 pcs · Thread outlet: M8x1.25 (standard thread) · Hole pattern [mm]: 56 (61) x 56 · Decompressor: M10x1.5 · Camouflaged: No · Area of application: Tuning

GPO pinion 14 teeth | Sachs 50/3, 50/4

Chain type: 415H · Manufacturer: GPO · Material: Steel · Surface: sandblasted · Chain pitch: 1/2" x 3/16" · Number of teeth: 14 pcs · Recording type: Ø15 x SW12 · Thickness: 4.4 mm · Cranking (offset): 14.5 mm

GPO sprocket 15 teeth | Sachs 50/3, 50/4

Chain type: 415H · Manufacturer: GPO · Material: Steel · Surface: sandblasted · Chain pitch: 1/2" x 3/16" · Number of teeth: 15 pcs · Recording type: Ø15 x SW12 · Thickness: 4.4 mm · Cranking (offset): 14.5 mm

Athena 48 mm cylinder kit incl. diaphragm | Sachs (504), 505, 508

Manufacturer: Athena · Camouflaged: No · Surface: sandblasted · Nominal diameter: 48 mm · Material: Aluminum · Crankshaft stroke: 44 mm · Ø piston pin (B): 12 mm · Ø cylinder neck: 51.8 mm · Ø Outlet outside: 26 mm · Ø outlet inside: 19.4 mm · Ø Inlet inside: 14.7 mm · Ø Inlet inside: 17.8 mm · Inlet window: 31.9 x 36.2 · Thread inlet: M5x0.8 (standard thread) · Hole spacing inlet: 32.5 mm · Number of fixing points: 4 pcs · Hole spacing outlet: 50 mm · Area of application: Tuning · Outlet type: clamped · Outlet type: straight · Thread outlet: M8x1.25 (standard thread) · Hole pattern [mm]: 56/60 x 56 · Decompressor: M10x1.5

Athena 48 mm cylinder kit | Sachs 503 AB, AC, ADV

Manufacturer: Athena · Camouflaged: No · Surface: sandblasted · Displacement: 80 ccm · Nominal diameter: 48 mm · Material: Aluminum · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Ø Outlet outside: 26 mm · Thread inlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Area of application: Tuning · Outlet type: clamped · Outlet type: slanted · Thread outlet: M6x1 (standard thread)

Kickstart lever folding straight | Sachs

Material: Metal · Total length: 120 mm

38 mm cylinder kit round intake | Sachs 50/3, 50/4

Material: Gray cast iron · Camouflaged: No · Surface: varnished · Displacement: 50 ccm · Nominal diameter: 38 mm · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Hole spacing inlet: 31 mm · Number of fixing points: 4 pcs · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 51 x 40 · Area of application: Tuning · Outlet type: Union nut · Thread outlet: MF40x1.5 (fine pitch thread)

swiing® revival crankshaft standard | Sachs 50/2, 50/3

Manufacturer: swiing® revival parts · Weight: 901 g · Material: Steel · Cheek type: standard · Thread type: MF10x1 (fine pitch thread) · Crankshaft stroke: 42 mm · Ø piston pin (B): 12 mm · Connecting rod length center-center: 85 mm · Number of gears: 1 pcs · Number of gears: 3 pcs · Total length of crankpin on clutch side: 40.6 mm · Total length crankpin ignition side: 63.2 mm · Ø crank webs: 30 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 15 mm · Ø Bearing seat (ignition side): 15 mm · Thread length: 8 mm · Thread length: 11 mm · Area of application: Standard · Dimension needle bearing: 12 / 15 x 14.2 mm (axe 12) · Length 1st paragraph: 18.7 mm · Length 2nd paragraph: 14 mm · Ø 1st step (on the coupling side): 15 mm · Ø 2nd shoulder (on the clutch side): 12 mm · Length of shoulder (ignition side): 34 mm · Pony OEM number: A2565 · Sachs OEM number: 0286 139 400

GPO clutch trigger Sachs 502 / 503 (M27x1.25 / M20x1)

Width across flats (trigger): 27 mm · Manufacturer: GPO · Width across flats Screw: 19 mm · Material: Steel · Surface: blackened · Total length: 57 mm · Thread type: MF20x1 (fine pitch thread) · Thread type: MF27x1.25 (fine pitch thread) · Area of application: (Dis)assembly tool · Strength class: 8.8
